Dayton Audio 600-HPF-4 High Pass Speaker Crossover 600 Hz 12 DB/Octave

Quick OverviewThis 2nd order (i.e. 12 dB per octave) high pass Linkwitz-Riley filter from Dayton Audio passes frequencies above 3,500 Hz and can easily be combined with other filters in this series to create 2-way or even 3-way crossover networks. By using combinations of these filters you can create complete 2-way or 3-way crossovers. This 12dB/octave 3,500 Hz high pass filter can be combined with our 3,500 Hz low pass for a 2nd order Linkwitz-Riley crossover, which sums for flat transfer function across the crossover frequency. Specifications: Type: High Pass Filter Frequency: 3,500 Hz Impedance: 4 ohms Dimensions: 100 mm x 60 mm Power handling: 250 watts Series capacitor value: 5.7 µF Parallel inductor value: 0.36 mH Product Details Model Number 3.5k-HPF-4 List Price $10.99 Unit of Measure Each UPC 848791004339 Warranty - Parts 5 Years Warranty - Labor 5 Years Product Shipping Weight (lbs.) 0.6 Product Weight -- Product Height -- Product Width -- Product Length -- Product Depth -- High quality poly capacitor in series with the driver High quality components are securely fastened to PCB High quality red PC board with EVA backing to prevent shorts and vibration Dual 0.205 terminals at each connection point for easy parallel wiring
